MODULES FOR ET 200S, 2 DI 230V AC 15 MM WIDTH 5 PIECES PER PACKAGING UNIT MODULES FOR ET 200S, 2 DI 120V AC 15 MM WIDTH 5 PIECES PER PACKAGING UNIT MODULES ET 200S: 4DI UC 24V.48V, 15 MM WIDTH, WITH LED SF (GROUP FAULT), 5 PIECES PER PACKAGING UNIT MODULE FOR ET 200S, 8 DI SOURCE INPUT 24V DC, 15 MM WIDTH, 1 PIECE PER PACKAGING UNIT
MODULES FOR ET 200S, 8 DI DC 24V, 15 MM WIDTH, 100 PIECES PER PACKAGING UNIT MODULE FOR ET 200S, 8 DI DC 24V 15 MM WIDTH, 1 PIECE PER PACKAGING UNIT MODULES FOR ET 200S, 4 DI SOURCE INPUT 24V DC, 15 MM WIDTH, 5 PIECES PER PACKAGING UNIT LED SF (GROUP FAULT) 5 PIECES PER PACKAGING UNIT MODULES FOR ET 200S, 4 DI HIGH FEATURE 24V DC, 15 MM WIDTH WITH PARAM. MODULES FOR ET 200S, 4 DI STANDARD 24V DC, 15 MM WIDTH, 5 PIECES PER PACKAGING UNIT MODULES FOR ET 200S, 2 DI HIGH FEATURE 24V DC, 15 MM WIDTH WITH PARAM. MODULES FOR ET 200S, 2 DI STANDARD 24V DC, 15 MM WIDTH, 5 PIECES PER PACKAGING UNIT Greater energy efficiency due to system-integrated PROFIenergy Module and terminal box can be replaced during operation ( "hot swapping")Ĭonsistent shielding of conductor via terminal box and backplane bus to the PROFINET cable Minimal space required in the control cabinetĬompact dimensions, suitable for 80 mm standard control cabinets The station can be expanded up to 64 modules (depending on the interface module)
#Siemens simatic et 200sp code
Maximum clarity due to the use of color and reference code plates, as well as labeling strips Improved accessibility of the wiring due to new arrangement of the spring NC contacts alongside the associated conductor aperture Simple system-integrated expansion with additional potential through potential distribution modules No tools needed for one-handed wiring using push-in terminals SIMATIC ET 200SP is constructed with IP 20 protection and designed for installation in a control cabinet.ĭepending on the selected header module (interface module, S7-1500, SP-CPU, or open controller) and parameter assignment, there are different limit values which restrict the maximum configuration of an ET 200SP station.įree selection of the PROFINET connection system and characteristics via bus adapter Thanks to its scalable design, you can gear the I/O station exactly to the on-site requirements. SIMATIC ET 200SP is a multifunctional distributed I/O system for a wide range of applications. The pack of 10 units enables the amount of waste to be reduced considerably, as well as saving the time and cost of unpacking individual modules. * Motor starters as direct on-line starters (DS) and reversing starters (RS)Īpart from the standard type of delivery in an individual package, selected I/O modules and BaseUnits are also available in a pack of 10 units. * Special modules, with color coding mint green * Communications modules (CM), with color coding light gray * Technology modules (TM), with color coding turquoise * Analog output modules (AQ), with color coding dark blue * Analog input modules (AI), with color coding light blue * Digital output modules (DQ), with color coding black * Digital input modules (DI), with color coding white Alternatively, as further head-end stations, various PLC, F-PLC and Open Controllers are available as compact S7-1500 controllers (Distributed Controllers).ĮT 200SP components are available as SIPLUS version for extreme requirements and a high degree of robustness.įor ET 200SP, a comprehensive range of I/O modules, including fail-safe versions, is available: Via an interface module with PROFINET or PROFIBUS interface it can exchange IO data of the connected I/O modules with a higher-level control system. The scalable SIMATIC ET 200SP I/O system is a highly flexible, modular I/O system with IP20 degree of protection.
